Input Voltage Range | 340 V to 480 V AC 360 V to 480 V AC 360 V to 460 V AC Customize |
Output Voltage | 415 V ± 1% (Variable 5%) OR Customize |
Frequency | 47 Hz to 53 Hz |
Power Capacity | 3 kVA to 100 kVA |
Cooling | Air Cooled |
Voltage Regulation | ±1 % |
Duty Cycle | Continues |
Wave-form distortion | Nil |
Ambient | 0 to 45° C |
Environment | Designed for indoor tropical use |
Mounting | Free on wheel |
Controls | 1. Keypad & LCD to set O/P Voltage & other parameters 2. Auto/ Manual switch to select mode 3. Increase /Decrease switch to Control O/P voltage in manual mode |
Protection | 1. Under/Over voltage cut off at output 2. Under/Over Voltage cut off at input 3. True electronics over load protection 4. Over load & short circuit protection using MCB & MCCB |
Meter | I/P Voltage , O/P Voltage & Load Current of Three Phase on Single LCD Screen |
Indications | 1. I/P Under/Over Voltage Cut-off on LCD screen 2. O/P Under/Over Voltage Cut-off on LCD screen 3. Over load cut-off on LCD screen |
